Audio-Technica ATW-3141bI Wireless Handheld System
  • Audio-Technica ATW-3141bI Wireless Handheld System

Special Order


Item Code: PAAUH00242 Part Number: ATW-3141bI

Audio-Technica ATW-3141bI Wireless Handheld System

Be the first to review this product

$819.00 Our Price

No Interest & No Payment for 6 months when you purchase this product in-store. [see financing options]

Bundled With

Original Price

Bundled Savings


Sale Price

Final Sale Item

Canada Computers Tech Protection

Order Online and Pick Up In-Store In-Store Special Order


The Audio-Technica ATW-3141bI Wireless Handheld System is a frequency agile, true-diversity handheld wireless microphone system that includes the ATW-R3100bI receiver and the ATW-T341bI handheld transmitter. This system is tuned to band I (655.500-680.375 MHz), but is also available in bands C (541.500-566.375 MHz) and D (655.500-680.375 MHz).


The ATW-R3100bI Receiver features Automatic Frequency Scanning, which selects the best available frequency. The True Diversity feature means that the ATW-R3100bI has two independent receiver sections, and automatically sends the strongest signal of the two to the output at any given moment.

The rear panel reveals both unbalanced 1/4" TS and balanced XLR outputs. A comprehensive back-lit LCD display reveals channel and frequency settings, signal status and transmitter battery status. The receiver also offers a ground lift switch, convenient in situations where bad power feeds result in ground hum and noise on the output stage.

The ATW-T341bI Handheld Transmitter is equipped with an AE4100 cardioid dynamic element. The cardioid polar pattern effectively minimizes noise and feedback at the off-axis sections. The mic has a dual output section that lets you select high or low power, depending on your needs. The low power setting uses up the mic's two AA batteries more slowly. The mic can get up to 8 hours of life in that setting. On the high power setting, you get up to 6 hours of operation before needing to change batteries.


ATW-R3100bI Receiver

  • - Automatic frequency scanning

  • - High sensitivity dual IF receiving design for dropout-free performance

  • - High-efficiency compander

  • - Three compatible frequency bands with 996 - 1001 selectable UHF frequencies per band

  • - 25 kHz frequency spacing makes it easier to find a clear, open frequency in crowded RF environments

  • - Nine pre-coordinated frequency scan groups simplify selection of usable frequencies in a multi-channel wireless system

  • - Receiver internal function menu with soft-touch controls

  • - Digital Tone Lock squelch

  •  -Adjustable receiver squelch

  • - Transmitter battery-life fuel gauge on the front panel

  • - Operator alert indicators

  • - True diversity receiver with silent, automatic switching

  • - AC or 12-18V DC operation

  • - Rear-panel antenna mount options

  • - Antenna power available for powered antennas & other in-line RF devices

  • - Balanced and unbalanced outputs

  • - Output level control on the rear panel

  • - Ground lift switch on balanced output

  • - Receiver mounts in a single rack space (1 or 2 units)


ATW-T341bI Handheld Transmitter

  • - Artist Elite AE4100 cardioid dynamic capsule with integral shock mount

  • - Dual output power selection to optimize battery life

  • - Battery fuel gauge on the body of the microphone

  • - Dual-color power/mute status indictor

  • - Backlit LCD status display

  • -  82.000-507.000 MHz Frequency range

  • - Two-stage pop filter to protect against "p" pops

  • - Function menu displayed in a backlit LCD window and controlled by internal touch switches

  • - Power/mute lock provision

  • - 18 dB audio input level adjustment

  • - Digital Tone Lock to identify the wireless transmitter to the receiver

  • - Operates on two AA batteries

  • - Durable Metal housing

  • - Supplied with a heavy-duty microphone stand clamp


Type of System Frequency-Agile True Diversity UHF Wireless
Operating Frequencies UHF Band I: 482.000-507.000 MHz (1001 frequencies, 25 kHz increments)
Miscellaneous Minimum Frequency Step: 25 kHz
Maximum Deviation: ±35 kHz
Modulation Mode FM
Dynamic Range >110 dB (A-Weighted), Typical
THD <1% (at 1 kHz, ±17.5 kHz Deviation)
Operating Range 300' (100 m) typical (open range environment with no interfering signals)
Operating Temperature Range 23° F(-5° C) to 113° F(+45° C) Battery and LCD performance may be reduced at very low temperatures
Frequency Response 70 Hz to 15 kHz (+1 dB, -3 dB)
Type of Receiver True Diversity
Image Rejection 60 dB Nominal, 55 dB Minimum
Type of Outputs Unbalanced: 1/4" TS ("Mono") Phone Jack
Balanced: XLRM-type
RF Sensitivity 24 dBuV at 60 dB S/N ratio (50? Termination)
Maximum Output Level Balanced: +9 dBV
Unbalanced: +7 dBV
Output Connectors Unbalanced: 1/4"
Balanced: XLR
Antenna Inputs BNC-Type, 50?
Bias Voltage 12V DC, 60 mA, Each
Power Requirements 12-18V DC, 500 mA
Dimensions (WxDxH) 8.27 x 6.47 x 1.73" (210.0 x 164.4 x 44mm)
Not Including BNC Connectors or Feet
Weight 10 oz (284 g)
Type of Transmitter ATW-T341b Handheld
Type of Microphone Dynamic
Polar Pattern Cardioid
RF Power Output High: 30 mW; Low: 10 mW (Switchable), at 50?
Spurious Emission Following Federal and National Regulations
Battery Type/Approx. Life (2) 1.5V AA Alkaline (Not Included)
Battery Life High: 6 Hours (Alkaline), Low: 8 hours (Alkaline)
Depending on Battery Type and Use Pattern
Mute Switch Power / Mute Switch Dual Function
Display Back-lit LCD Display & Battery / Signal Status LED
Dimensions (L x D) 9.33 x 1.89" (237.0 x 48 mm)
