Audio-Technica AEW-R5200 Dual UHF Diversity Receiver (Band C - 541.500 MHz - 566.375 MHz)
  • Audio-Technica AEW-R5200 Dual UHF Diversity Receiver (Band C - 541.500 MHz - 566.375 MHz)
  • Audio-Technica AEW-R5200 Dual UHF Diversity Receiver (Band C - 541.500 MHz - 566.375 MHz)
  • Audio-Technica AEW-R5200 Dual UHF Diversity Receiver (Band C - 541.500 MHz - 566.375 MHz)
  • Audio-Technica AEW-R5200 Dual UHF Diversity Receiver (Band C - 541.500 MHz - 566.375 MHz)
  • Audio-Technica AEW-R5200 Dual UHF Diversity Receiver (Band C - 541.500 MHz - 566.375 MHz)
  • Audio-Technica AEW-R5200 Dual UHF Diversity Receiver (Band C - 541.500 MHz - 566.375 MHz)
  • Audio-Technica AEW-R5200 Dual UHF Diversity Receiver (Band C - 541.500 MHz - 566.375 MHz)

Special Order


Item Code: PAAUH00232 Part Number: AEW-R5200C

Audio-Technica AEW-R5200 Dual UHF Diversity Receiver (Band C - 541.500 MHz - 566.375 MHz)

Be the first to review this product

$3,189.00 Our Price

No Interest & No Payment for 6 months when you purchase this product in-store. [see financing options]

Bundled With

Original Price

Bundled Savings


Sale Price

Final Sale Item

Canada Computers Tech Protection

Order Online and Pick Up In-Store In-Store Special Order


From Audio Technica, the AEW-R5200 dual receiver is designed for use with the 5000 series wireless microphone system. The receiver features two independent receivers with 200 UHF selectable frequencies each, enabling two transmitters to operate simultaneously. Diversity reception minimizes drop-out and RF interference, resulting in the strongest possible reception.


The rear panel reveals independent balanced 1/4" Phone and balanced XLR outputs. A comprehensive back-lit LCD display reveals channel and frequency settings, signal status and transmitter battery status.

The 5000 series enhanced features include IntelliScan which automatically sets best available frequencies on all linked receivers, and Dual Compandor circuitry which processes high and low frequency signal separately resulting in superior audio quality.


  • Dual Receiver Operation

  • The AEW-R5200 features dual internal receivers that enable simultaneous operation of two transmitters.


  • Frequency Agile

  • The system operates on UHF frequencies allowing greater channel selection and range. The transmitter and receiver feature 200 user selectable channels.


  • RJ45 Jack

  • The Networn Interface connection enables software based remote control (included) with an external PC.


  • Diversity Reception

  • The AEW-R5200 receiver features dual internal receivers. The receivers relay between each-other, vying for the strongest reception while minimizing noise and signal drop-out.


  • Blue Back-Lit LCD

  • Both receiver and transmitters feature a comprehensive, white over blue background LCD display. The display provides radio frequency and channel information, battery and signal status.


  • IntelliScan

  • The IntelliScan feature automatically locates and sets best available frequencies on all linked receivers.


Type of Receiver Dual independent receivers, automatic-switching diversity
RF Carrier Frequency Range Band C - 541.500 MHz - 566.375 MHz
Approx. Working Range 300 feet
Overall Frequency Response 70 Hz to 15 kHz
Signal-to-Noise Ratio 115 dB at 40 kHz deviation (IEC-weighted), maximum modulation 75 kHz
# Of Channels 200 Channels
Type of Output(s) 2 - Balanced: XLRM-type
2 - Balanced: 1/4" TRS phone jack
Headphone Monitoring 1/4" TRS Phone
Power Requirements 100-240V AC 50/60 Hz; 15W
Battery Type/Approx. Life AC Powered Only
Display Back-Lit LCD Display & Battery / Signal Status LED
Mounting Options Table Surface / Rack Mountable rack ears included
Antenna Type BNC Flexible UHF
Dimensions (W x H x D) 18.98 x 1.74 x 10.85" (48.20 x 4.40 x 27.55mm)
Weight 8.8 lbs (4 kg)
