Audio-Technica AEW-R4100 UHF Diversity Receiver for 4000 Series System (Band C - 541.500 MHz to 566.375 MHz)
  • Audio-Technica AEW-R4100 UHF Diversity Receiver for 4000 Series System (Band C - 541.500 MHz to 566.375 MHz)

Special Order

Item Code: PAAUH00233 Part Number: AEW-R4100C

Audio-Technica AEW-R4100 UHF Diversity Receiver for 4000 Series System (Band C - 541.500 MHz to 566.375 MHz)

Be the first to review this product

$1,049.00 Our Price

No Interest & No Payment for 6 months when you purchase this product in-store. [see financing options]

Bundled With

Original Price

Bundled Savings

Sale Price

Final Sale Item

Not Available Online In-Store Special Order

From Audio Technica, the AEW-R4100 receiver is designed for use with the 4000 series wireless microphone system. The receiver features frequency adjustable UHF reception, allowing access of up to 200 user selectable channels. Diversity reception allows 2 built-in, independent receivers to relay on a single frequency for the strongest possible reception.

The rear panel reveals both unbalanced 1/4" Phone and balanced XLR outputs. A comprehensive back-lit LCD display reveals channel and frequency settings, signal status and transmitter battery status. The 4000 series enhanced features include IntelliScan which automatically sets best available frequencies on all linked receivers, and Dual Compandor circuitry which processes high and low frequency signal separately resulting in superior audio quality.

  • Frequency Agile

  • The system operates on UHF frequencies allowing greater channel selectability and range. The transmitter and receiver feature 200 user selectable channels.

  • Diversity Reception

  • The AEW-R4100 receiver features dual internal receivers. The receivers relay between each-other, vying for the strongest reception while minimizing noise and signal drop-out.

  • Blue Back-Lit LCD

  • Both receiver and transmitters feature a comprehensive, white over blue background LCD display. The display provides radio frequency and channel information, battery and signal status.

  • IntelliScan

  • The IntelliScan feature automatically locates and sets best available frequencies on all linked receivers.

Type of Receiver Dual independent receivers, automatic-switching diversity
RF Carrier Frequency Range Band C - 541.500 MHz to 566.375 MHz
Approx. Working Range 300 feet
Overall Frequency Response 70 Hz to 15 kHz
Signal-to-Noise Ratio 115 dB at 40 kHz deviation (IEC-weighted), maximum modulation 75 kHz
# Of Channels 200 Channels
Type of Output(s) Unbalanced: 1/4" TS ("mono") phone jack
Balanced: XLRM-type
Headphone Monitoring 1/4" TRS Phone
Power Requirements 100-240V AC 50/60 Hz; 8W
Battery Type/Approx. Life (2) 1.5v AA Alkaline not included
Display Back-Lit LCD Display & Battery / Signal Status LED
Mounting Options Table Surface / Rack Mountable rack ears included
Antenna Type Internal
Dimensions (W x H x D) 8.31 x 1.74 x 9.26" (211.0 x 44.0 x 235.0mm)
Weight 2.4 lbs (1.1 kg)
Transmitter AEW-T3300 Handheld Transmitter
Type of Transmitter Frequency Agile Handheld
Type of Microphone Condenser
Polar Pattern Cardioid
Interchangeable Mic Heads No
Mute Switch Power / Mute switch dual function
Level Control No
