Audio-Technica ATW-3110 Wireless Body-Pack System
  • Audio-Technica ATW-3110 Wireless Body-Pack System | Includes: ATW-R310 Receiver and ATW-T310 UniPak Transmitter (No Mic) (Band C - 541.500 - 566.375 MHz)

Special Order


Item Code: PAAUH00239 Part Number: ATW-3110bC

Audio-Technica ATW-3110 Wireless Body-Pack System
Includes: ATW-R310 Receiver and ATW-T310 UniPak Transmitter (No Mic) (Band C - 541.500 - 566.375 MHz)

Be the first to review this product

$659.00 Our Price

No Interest & No Payment for 6 months when you purchase this product in-store. [see financing options]

Bundled With

Original Price

Bundled Savings


Sale Price

Final Sale Item

Canada Computers Tech Protection

Order Online and Pick Up In-Store In-Store Special Order


The Audio Technica 3000 Series wireless systems provide reliable, professional UHF technology for the most demanding of applications. The ATW-3110 is a frequency agile, true-diversity body-pack wireless microphone system including the ATW-R310 receiver and ATW-T310 UniPak Transmitter. The absence of a microphone allows users the freedom to choose any of the Audio-Technica UniPak compatible microphones or cables as desired.


The ATW-R310 receiver features frequency adjustable UHF reception, allowing access of up to 200 user selectable channels. Diversity reception allows 2 build-in, independent receivers to relay on a single frequency for the strongest possible reception. The rear panel reveals both unbalanced 1/4" Phone and balanced XLR outputs. A comprehensive back-lit LCD display reveals channel and frequency settings, signal status and transmitter battery status. The receiver also features a ground lift switch, convenient in settings where bad power feeds result in ground hum and noise on the output stage.

The ATW-T310 body-pack transmitter features Audio-Technica's unique UniPak input connector. The input conveniently accepts both line and microphone level signal (adjustable) allowing instrument signal as well as microphone signals. An assortment of compatible microphones and instrument cables are available from Audio-Technica. The light weight transmitter operates on 2-AA Alkaline batteries for up to 6 hours (High) and 8 hours (Low).


  • Frequency Agile

  • The system operates on UHF frequencies allowing greater channel selectability and range. The transmitter and receiver feature 200 user selectable channels.


  • Diversity Reception

  • The ATW-R310 receiver features dual internal receivers. The receivers relay between each-other, vying for the strongest reception while minimizing noise and signal drop-out.


  • UniPak Transmitter

  • Audio-Technica's UniPak transmitter is a body-pack with an input connection designed for low and high impedance signal. This makes the transmitter versatile enough to handle microphone and line level signals.


Type of System UHF Frequency Agile Body-Pack
RF Carrier Frequency Range Band C: 541.500 - 566.375 MHz
Approx. Working Range 300 feet
Overall Frequency Response 70 Hz to 15 kHz
Signal-to-Noise Ratio 110 dB at 35 kHz deviation (IEC-weighted), maximum modulation 75 kHz
# Of Channels 200 Channels
# Of Simultaneous Systems 6
Type of Receiver Dual independent receivers, automatic-switching diversity
Type of Outputs Unbalanced: 1/4" TS ("mono") phone jack
Balanced: XLRM-type
Headphone Monitoring No
Power Requirements 120V AC 60 Hz; 12-18V DC, 500 mA, center positive, with external supply
Battery Type/Approx. Life (2) 1.5v AA Alkaline not included
Display Back-Lit LCD Display & Battery / Signal Status LED
Mounting Options Table Surface / Rack Mountable rack ears included
Antenna Type BNC Flexible UHF
Dimensions (W x H x D) 2.60 x 3.43 x 0.94" (66.0 x 87.0 x 24.0mm)
Weight 2.8 oz (80 grams)without batteries
Type of Transmitter Frequency Agile Body-Pack
Type of Input Connector High Impedance / Low Impedance / Bias UniPak Connection
Type of Microphone microphone not included with this system
Polar Pattern not applicable
Interchangeable Mic Heads Various AKG microphones and cables featuring UniPak connection
Mute Switch Power / Mute switch dual function
Level Control Input Level Control: -6dB / 0dB / +6dB / +12dB
