Audio-Technica ATW-3110b Wireless Body-Pack System
  • Audio-Technica ATW-3110b Wireless Body-Pack System

Special Order


Item Code: PAAUH00240 Part Number: ATW-3110bI

Audio-Technica ATW-3110b Wireless Body-Pack System

Be the first to review this product

$659.00 Our Price

No Interest & No Payment for 6 months when you purchase this product in-store. [see financing options]

Bundled With

Original Price

Bundled Savings


Sale Price

Final Sale Item

Canada Computers Tech Protection

Order Online and Pick Up In-Store In-Store Special Order


The Audio-Technica ATW-3110b Wireless Body-Pack System is a frequency agile, true-diversity system that includes the ATW-R310 receiver and ATW-T310 UniPak transmitter. The absence of a microphone allows users the freedom to choose any of the Audio-Technica UniPak compatible microphones or cables as desired.


The ATW-R310b receiver features frequency adjustable UHF reception, allowing access of up to 996 user selectable channels. Diversity reception allows 2 built-in independent receivers to relay on a single frequency for the strongest possible reception. The rear panel reveals both unbalanced 1/4" phone and balanced XLR outputs. A comprehensive back-lit LCD display reveals channel and frequency settings, signal status and transmitter battery status. The receiver also features a ground lift switch, convenient in settings where bad power feeds result in ground hum and noise on the output stage.


The ATW-T310b body-pack transmitter features Audio-Technica's unique UniPak input connector. The input conveniently accepts both line and microphone level signals (adjustable) allowing instrument signals as well as microphone signals. An assortment of compatible microphones and instrument cables are available from Audio-Technica. The lightweight transmitter operates on 2 AA alkaline batteries for up to 6 hours (High) and 8 hours (Low).


  • - 996 - 1001 UHF frequencies in one of three UHF frequency ranges


  • - Available in three frequency bands:
    541.500 MHZ to 566.375 MHz (TV Channels 25 - 30)
    655.500 MHz to 680.375 MHz (TV Channels 44 - 49)
    482.000 MHz to 507.000 MHz (TV Channels 16 -20)


  • - Antenna power available for powered antennas & other in-line RF devices

  • - Nine pre-coordinated frequency scan groups simplify selection of usable frequencies in a multi-channel wireless system

  • - True Diversity operation reduces dropouts

  • - Advanced digital Tone Lock squelch effectively blocks stray RF and communicates transmitter data for receiver display

  • - Transmitters offer back-lit LCD & dual-color LED

  • - Locking battery compartment with secure latch and robust design

  • - Ground-lift switch helps eliminate audible hum caused by ground loops

  • - Balanced and unbalanced audio output jacks

  • - ATW-T310b UniPak transmitter includes Super Hi-Z input that provides optimum load for guitar pickups

  • - ATW-T341b handheld microphone/transmitter features the Artist Elite AE4100 cardioid dynamic element

  • - ATW-T371b handheld microphone/transmitter features the Artist Series ATM710 cardioid condenser element


Type of System UHF Frequency Agile Body-Pack
RF Carrier Frequency Range Band I: 482.000 to 507.000 MHz
Approx. Working Range 300 feet (91.44m)
Overall Frequency Response 70Hz-15kHz
Signal-to-Noise Ratio 110dB at 35kHz deviation (IEC-weighted), maximum modulation 75 kHz
# Of Channels 1001 Channels
Type of Receiver Dual independent receivers, automatic-switching diversity
Type of Outputs Unbalanced: 1/4" TS ("mono") phone jack
Balanced: XLRM-type
Headphone Monitoring No
Power Requirements 120VAC 60 Hz; 12-18VDC, 500mA, center positive, with external supply
Battery Type/Approx. Life (2) 1.5v AA Alkaline not included
High: 6 hours (alkaline)
Low: 8 hours (alkaline)
Depending on battery type and use pattern
Display Back-Lit LCD Display & Battery / Signal Status LED
Mounting Options Table Surface / Rack Mountable rack ears included
Antenna Type BNC Flexible UHF
Dimensions (W x D x H) 8.27 x 6.47 x 1.73" (210.0 x 164.4 x 44mm)
Weight 2.9 oz (81 grams) without batteries
Type of Transmitter Frequency Agile Body-Pack
Type of Input Connector High Impedance / Low Impedance / Bias UniPak Connection
Type of Microphone microphone not included with this system
Polar Pattern not applicable
Interchangeable Mic Heads Various AKG microphones and cables featuring a UniPak connection
Mute Switch Power / Mute switch dual function
RF Output Power High: 30mW, Low: 10mW (switchable), at 50 ohms
Dimensions (W x H x D) 2.60 x 3.43 x 0.94" (66.0 x 87.0 x 24.0mm)
