Audio-Technica 2000 Series ATW-2194bI Wireless System
  • Audio-Technica 2000 Series ATW-2194bI Wireless System

Special Order


Item Code: PAAUH00252 Part Number: ATW-2194bI

Audio-Technica 2000 Series ATW-2194bI Wireless System

Be the first to review this product

$909.00 Our Price

Bundled With

Original Price

Bundled Savings


Sale Price

Final Sale Item

Canada Computers Tech Protection

Order Online and Pick Up In-Store In-Store Special Order


The 2000 Series ATW-2194bI Wireless System from Audio-Technica includes the ATW-R2100b Receiver, ATW-T210a UniPak Transmitter, and MicroSet Cardioid Headworn Microphone. The kit can be used for a variety of applications for live stage, fixed installations, rehearsals, public speaking, A/V rental houses, places of worship, and more. The transmitter and receiver support a frequency band of 487.125 to 506.500 MHz. The black microphone captures audio to provide professional-grade audio in applications such as for stage, television, lecturers, houses of worship, and more.


2000 Series ATW-2110b Wireless UHF Bodypack System


The ATW-2110b Wireless UHF Bodypack System from Audio-Technicabridges the gap between affordable wireless technology and professional level quality. It includes an ATW-T210 UniPak bodypack transmitter and an ATW-R2100 diversity UHF receiver that can be used when paired with a lavalier microphone in a variety of applications for live stage, fixed installations, rehearsals, public speaking, A/V rental houses, places of worship, and more.


The ATW-R2100 receiver features True Diversity operation and selects between two receiver sections, reducing dropouts and radio frequency interference. Furthermore, it features 10 user selectable UHF frequencies, allowing 10 systems to be used simultaneously. Single touch frequency scanning automatically selects clear frequencies in the area. The rear panel features a balanced XLR output and an unbalanced 1/4" phone connection. A back-lit LCD provides channel, AF, RF and diversity status information.

The ATW-T210 UniPak transmitter is a lightweight bodypack microphone transmitter that operates on the same frequencies as the receiver. The transmitter features a 4-pin Hirose connection input that is compatible with Audio-Technica "CW" lavaliers and headworn microphones, and select instrument cables. The transmitter operates up to 9 hours on two 1.5V AA batteries.


    • Ground-lift switch helps eliminate audible hum caused by ground loops between the sound system and receiver

    • Includes rack-mount kit and detachable UHF antennas

    • Switchable transmitter power output with high and low settings offered

    • Balanced XLR and unbalanced 1/4" output jacks enable use with a wide variety of audio gear

    • Rugged metal half-rack receiver with soft-touch controls and LCD display

    • Tone Lock tone squelch system fights interference

    • True Diversity operation selects the better signal from the two receiver sections, reducing dropouts

    • Antenna power available for powered antennas & other in-line RF devices

    • 10 compatible user-switchable channels in one of two UHF frequency ranges

    • Automatic frequency scanning

    • Clear sound quality and rock-solid, dependable performance

    • Serious advances in affordable professional wireless


BP894 Subminiature Cardioid Condenser Headworn Microphone with Power Module (Black)


The black BP894 Subminiature Cardioid Condenser Headworn Microphone with Power Module from Audio-Technica is for capturing audio. It is used to provide professional-grade audio in applications such as for stage, television talent, lecturers, houses of worship, and more. It features a cardioid polar pattern and a frequency response of 20 to 20,000 Hz. The microphone requires 11 to 52V phantom power for operation.


The BP894 is built with a 55" permanently attached miniature cable. Its free end connects to the provided AT8539 power module using a 4-pin connector. This connector is also compatible with all Audio-Technica UniPak bodypack transmitters. The output of the power module is a 3-pin XLRM-type connector. A recessed switch in the power module allows the choice of a flat response or a low-frequency roll-off (via integral 80 Hz high-pass filter) to help control undesired ambient noise. This microphone includes a power module, cable clip, dual-ear mount, two windscreens, a moisture guard, a belt clip and a protective carrying case.

    • This microphone handles high sound pressure levels easily

    • The microphone features a low-profile design with a diameter of just 2.8 mm

    • The UniSteep filter provides a steep low-frequency attenuation to improve sound pickup without affecting voice quality

    • Locking 4-pin microphone output connector is compatible with the included power module and all Audio-Technica UniPak bodypack wireless transmitters

    • Well-suited for the stage, television talent, lecturers, and houses of worship

    • Features a rotating capsule housing with talk-side indicator for use on either ear and allows great polar pattern placement


Type of System UHF Frequency Agile Diversity
RF Carrier Frequency Range Band bI: 487.125 to 506.500 MHZ
Approx. Working Range 300' typical (100 m)
Overall Frequency Response 100 Hz to 15 kHz
THD & Noise < 1% (at 1 kHz, ┬▒20 kHz deviation)
# Of Channels 10 Total
# Of Simultaneous Systems 10
Type of Receiver ATW-R2100 UHF Diversity Half-Rack Mount
Type of Outputs Balanced: XLR-male
Unbalanced: 1/4" Phone
Headphone Monitoring No
Power Requirements 12-18 VDC, 500 mA
Battery Type/Approx. Life Two 1.5 V AA alkaline
Mounting Options Rack-Mount Adapters (Included)
Antenna Type Replaceable 1/4 wave whip antenna
Dimensions (WxDxH) 2.60 x 0.89 x 3.63" (66 x 22.5 x 92.3 mm)
Weight 2.20 lb (1.0 kg)
Type of Transmitter ATW-T210 UniPak UHF Body-Pack Transmitter
Type of Input Connector 4-pin Hirose connection
Type of Microphone Wireless Essentials microphones and cables sold separately
Compatibility Compatible with Audio-Technica Wireless Essentials microphones / instrument cables featuring 4-pin Hirose connections
Mute Switch Off/On Switch
Level Control Instrument / Microphone Level Trim Controls
Display LED Battery Indicator
Return & Exchange 14 Days
Manufacturer Warranty 1 Year Manufacturer
Manufacturing Defect Exchange 30 Days Defective Exchange Only
Courtesy Warranty Repair Shipment Service 90 Days Courtesy MFG Warranty Repair Services
Charged Warranty Repair Shipment Service 1 Year Charge MFG Warranty Repair Services
Sales Condition Unopened items, in their original packaging must be returned or exchanged "as new" condition in 14 days. Defective products can be exchanged in 30 days for same model only. Store credits will be issued for EOL defective items.
