Audio-Technica ATW-R1500 Stompbox Receiver
  • Audio-Technica ATW-R1500 Stompbox Receiver

Special Order

Item Code: PAAUH00269 Part Number: ATW-R1500

Audio-Technica ATW-R1500 Stompbox Receiver

Be the first to review this product

$319.00 Our Price

No Interest & No Payment for 6 months when you purchase this product in-store. [see financing options]

Bundled With

Original Price

Bundled Savings

Sale Price

Final Sale Item

Canada Computers Tech Protection

Order Online and Pick Up In-Store In-Store Special Order

The ATW-R1500 Stompbox Receiver from Audio-Technica is a single-channel, pedalboard-mountable, digital wireless receiver that operates in the 2.4 GHz range. The Stompbox has a footswitch, two switched TRS balanced 1/4" outputs, and an output mode selector. With the tap of your foot you can toggle between outputs to switch amps or to mute and unmute one output without muting the other for convenient tuning. Its metal body has easy-to-read digital ID and transmitter battery level displays, and AF peak and pair indicator lights. The Stompbox can be paired up with to eight ATW-T1001 UniPak bodypack transmitters (sold separately), enabling you to easily switch between instruments without having to move a bodypack from one instrument to the next.

  • - Multi-pairing function to link a single receiver with up to eight bodypack transmitters

  • - Transmitter battery level display on receiver

  • - Housed in a strong metal stompbox-style body for reliable performance and pedalboard mounting

  • - Included hook & loop strips for adding receiver to effects pedalboard

Operating Frequency 2.4 GHz ISM band
Dynamic Range >109 dB (A-weighted), typical
Total Harmonic Distortion <0.05% typical
Operating Range 60' (18.3 m) radius, 120' (36.6 m) diameter typical Open range environment with no interfering signals
Operating Temperature Range 32 to 104°F (0 to 40°C)
Battery performance may be reduced at very low temperatures
Frequency Response 20 Hz to 20 kHz
Depending on microphone type
System Diversity (frequency/time/space)
Maximum Output Level 1/4" (6.3 mm), TRS balanced: +12 dBV
Power Supply 100 - 240 VAC (50/60 Hz) to 12 VDC 0.5 A switched mode external power supply
Dimensions 3.98 x 1.73 x 5.12" (101 x 44 x 130 mm)
Weight 19.9 oz (565 g)
