Audio-Technica AT8681 - UniMix Mic Combiner


The AT8681 combines the output signal from two microphones into one channel. The balance control attenuates each microphone by 6 dB (typical) at midpoint.


  • - Combines the outputs of two microphones into one channel

  • - The balance control allows for the attenuation of each mic signal by 6dB

  • - Rugged, rack-mountable design


Circuit Type Passive
Circuit Configuration (2) XLR (female) to (1) XLR (male)
Attenuation / Gain 33dB
Input Impedance 10 kOhms
Output Impedance 250 ohms
Inputs (2) XLR (female)
Outputs (1) XLR (male)
Maximum Input +15dBv (1% T.H.D. at 1kHz)
Dimensions 5.12 x 2.36 x 1.73 in. (130 x 60 x 44mm)
Weight 8.8 oz. (250g)
