Audio-Technica AT4060a Cardioid Condenser Microphone
  • Audio-Technica AT4060a Cardioid Condenser Microphone
  • Audio-Technica AT4060a Cardioid Condenser Microphone
  • Audio-Technica AT4060a Cardioid Condenser Microphone
  • Audio-Technica AT4060a Cardioid Condenser Microphone

Special Order


Item Code: PAAUH00218 Part Number: AT4060A

Audio-Technica AT4060a Cardioid Condenser Microphone

Be the first to review this product

$2,399.00 Our Price

No Interest & No Payment for 6 months when you purchase this product in-store. [see financing options]

Bundled With

Original Price

Bundled Savings


Sale Price

Final Sale Item

Canada Computers Tech Protection

Order Online and Pick Up In-Store In-Store Special Order


The AT4060a Cardioid Condenser Microphone is designed for use in demanding studio applications. The tube is hand-selected, individually aged and tested, then employed in a uniquely configured circuit for enhanced tube performance. Specially tuned elements improve the dynamic range and the allow the AT4060a to handle high SPLs without sacrificing high-frequency characteristics. Floating-construction mounting of the elements provides isolation from noise and vibration. The AT4060a operates in conjunction with the included tube microphone powering unit, featuring low-impedance output and a ground-lift switch.


  • - Vintage tube sound with the versatile performance necessary for the most demanding studio applications

  • - Hand-selected tubes are individually tested and aged to maintain peak performance

  • - Regulated and heavily filtered heater current prevents noise contamination of audio signal chain

  • - Wide dynamic range, low self-noise and high max SPL capability

  • - Large coupling transformer provides superior low-frequency linearity

  • - Dual-diaphragm capsule design maintains precise polar pattern definition across the full frequency range of the microphone

  • - The 2-micron-thick, vapor-deposited gold diaphragms undergo a five-step aging process so that the optimum characteristics achieved remain constant over years of use

  • - Precision-machined, nickel-plated brass, acoustic element baffle provides enhanced element stability and optimal sensitivity


Transducer Externally polarized (DC bias) condenser
Polar Pattern Cardioid
Frequency Response 20 Hz to 20000 Hz
Open Circuit Sensitivity -34 dB (19.9 mV) re 1V at 1 Pa
Impedance 200 ohms
Max Input Sound Level (SPL) 150 dB SPL, 1 kHz at 1% T.H.D.,
149 dB SPL, 1 kHz at 0.5% T.H.D.
Noise 19 dB SPL
Dynamic Range (Typical) 131 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio 75 dB, 1 kHz at 1 Pa
Power Requirements AT8560a tube microphone powering unit (100-240 VAC)
Output Connectors 3-pin XLRM-type (on tube microphone powering unit)
Cables 25' (7.6 m) cable with 6-pin XLR-type connectors for use between microphone and tube microphone powering unit
AC power cable
Dimensions Microphone: 8.5 x 2.1" / 215.0 x 53.4 mm
Tube microphone powering unit: 8.5 x 5.2 x 1.8" / 212.0 x 131.5 x 46.0 mm
Weight 1.4 lb / 645 g
Tube microphone powering unit: 1.3 kg
