Audio-Technica ATW-1101/G System 10 Digital Wireless Guitar Set
  • Audio-Technica ATW-1101/G System 10 Digital Wireless Guitar Set

Special Order


Item Code: PAAUH00258 Part Number: ATW-1101/G

Audio-Technica ATW-1101/G System 10 Digital Wireless Guitar Set

Be the first to review this product

$429.00 Our Price

Bundled With

Original Price

Bundled Savings


Sale Price

Final Sale Item

Canada Computers Tech Protection

Order Online and Pick Up In-Store In-Store Special Order


The ATW-1101/G System 10 from Audio-Technicais a digital wireless solution for your electric guitar or bass rig that includes the ATW-R1100 digital receiver, the ATW-T1001 UniPak pocket transmitter and the AT-GcW guitar cable. The ATW-1101/G uses 24-bit, 48 kHz digital audio and operates free from TV interference in the 2.4 GHz frequency range. Built for expandability, you can use up to eight systems simultaneously.


The ATW-1101/G is designed for quick and easy setup. Specifically for electric guitarists and bassists, it comes with the 36" AT-GcW guitar cable for connecting your guitar or bass to the ATW-T1001 UniPak pocket transmitter. Just plug the cable's 1/4" phone plug connector into your guitar, then plug the locking 4-pin connector on the other side into the pocket transmitter. Finally, just use a guitar cable to connect the unbalanced output on the ATW-R1100 digital receiver to your guitar amplifier's input and you are ready to go.


The ATW-1101/G wireless system is engineered to quickly find the best signal possible, utilizing an automatic frequency selection function that chooses open bands for you when you "pair" your transmitter with the receiver. Also designed to combat interference, the ATW-1101/G uses three different diversity techniques. Using frequency diversity, the system sends the wireless signal on two separate channels simultaneously and chooses the one with the clearest signal. It also transmits the signal across multiple intervals in time in order to fight multipath interference. This is known as time diversity. Furthermore, the system also makes use of space diversity, choosing between the receiver's dual antennas depending on which is picking up the best signal integrity.


  • - Unbalanced 1/4" output on receiver for connecting to guitar amp

  • - Balanced XLR output on receiver allows for connection to microphone level inputs on mixers

  • - Level controls on transmitter and receiver

  • - Pair indicator illuminates on receiver when synced with transmitter

  • - AF Peak indicator on receiver allows you to monitor the input stage on the transmitter for clipping


Operating Frequencies 2.4 GHz ISM band
Dynamic Range >109 dB (A-weighted), typical
Total Harmonic Distortion <0.05% typical
Operating Range 30 m (100') typical
Operating Temperature Range 0 to +40° C (32 to 104° F)
Frequency Response 20 Hz to 20 kHz
Audio Sampling 24 bit, 48 kHz
Receiving System Diversity (frequency/time/space)
Output Connections 1x XLR, balanced
1x 1/4" (6.3 mm), unbalanced
Maximum Output Level Balanced: 0 dBV
Unbalanced: +6 dBV
Power Supply 100-240V AC (50/60 Hz) to 12V DC 0.5A, center positive, switched mode external power supply
Dimensions 2.76 x 4.21 x .98" (70.2 x 107 x 24.9 mm)
Weight 3.5 oz (100 g), without batteries
RF Output Power 10 mW
Spurious Emission Following federal and national regulations
Input Connections 1x 4-pin locking connector
Wiring:
Pin 1: GND
Pin 2: INST INPUT
Pin 3: MIC INPUT
Pin 4: DC BIAS +9V
Batteries 2x 1.5V AA (not included)
Battery Life >7 hours (alkaline)
Type 1/4" TS Phone to 4-pin Connector
Length 36" (0.9 m)
Return & Exchange 14 Days
Manufacturer Warranty 1 Year Manufacturer
Manufacturing Defect Exchange 30 Days Defective Exchange Only
Courtesy Warranty Repair Shipment Service 90 Days Courtesy MFG Warranty Repair Services
Charged Warranty Repair Shipment Service 1 Year Charge MFG Warranty Repair Services
Sales Condition Unopened items, in their original packaging must be returned or exchanged "as new" condition in 14 days. Defective products can be exchanged in 30 days for same model only. Store credits will be issued for EOL defective items.
