Audio-Technica ATW-1101/H System 10 Digital Wireless Headworn Dynamic Microphone Set
  • Audio-Technica ATW-1101/H System 10 Digital Wireless Headworn Dynamic Microphone Set

Special Order


Item Code: PAAUH00259 Part Number: ATW-1101/H

Audio-Technica ATW-1101/H System 10 Digital Wireless Headworn Dynamic Microphone Set

Be the first to review this product

$499.00 Our Price

No Interest & No Payment for 6 months when you purchase this product in-store. [see financing options]

Bundled With

Original Price

Bundled Savings


Sale Price

Final Sale Item

Canada Computers Tech Protection

Order Online and Pick Up In-Store In-Store Special Order


The ATW-1101/H System 10 from Audio-Technicais a digital wireless headworn microphone solution for drummers, keyboardists, dancers, instructors and others that require the use of their hands during performance. The set includes the ATW-R1100 digital receiver, the ATW-T1001 UniPak pocket transmitter and the PRO 8HEcW headworn microphone. It uses 24-bit, 48 kHz digital audio and operates free from TV interference in the 2.4 GHz frequency range. Built for expandability, you can use up to eight systems simultaneously.


The PRO 8HEcW dynamic headworn microphone is designed to offer accurate, close range capture of an individual voice. The cushioned headband is designed to fit comfortably on your head and it can be worn on either the left or right side. The capsule features a hypercardioid polar pattern that promotes isolation of the vocal source by rejecting outside sound from floor monitors, drum sets, crowd noise, etc. This lends to consistent sound quality and high gain before feedback. The mic is fitted with a windscreen to filter out pops from breath and wind noise, and it has a dynamic Hi-ENERGY neodymium element that does not require phantom power. It has a 55" cable that terminates with a locking 4-pin connector which plugs into the ATW-T1001 UniPak pocket transmitter.


The ATW-1101/H wireless system is engineered to quickly find the best signal possible, utilizing an automatic frequency selection function that chooses open bands for you when you "pair" your transmitter with the receiver. Also designed to combat interference, the ATW-1101/H uses three different diversity techniques. Using frequency diversity, the system sends the wireless signal on two separate channels simultaneously and chooses the one with the clearest signal. It also transmits the signal across multiple intervals in time in order to fight multipath interference. This is known as time diversity. Furthermore, the system also makes use of space diversity, choosing between the receiver's dual antennas depending on which is picking up the best signal integrity.


  • - Balanced XLR output and unbalanced 1/4" output on receiver allows for connection to balanced microphone level inputs or unbalanced aux level inputs on mixers and sounds systems

  • - Flexible, pivoting boom allows mic to be worn on left or right side

  • - Headband cushions for support and comfort

  • - Level controls on transmitter and receiver

  • - Pair indicator illuminates on receiver when synced with transmitter

  • - AF Peak indicator on receiver allows you to monitor the input stage on the transmitter for clipping


Operating Frequencies 2.4 GHz ISM band
Dynamic Range >109 dB (A-weighted), typical
Total Harmonic Distortion <0.05% typical
Operating Range 30 m (100') typical
Operating Temperature Range 0 to 40° C (32 to 104° F)
Frequency Response 200 Hz - 18 kHz
Audio Sampling 24 bit, 48 kHz
Receiving System Diversity (frequency/time/space)
Output Connections 1x XLR, balanced
1x 1/4" (6.3 mm), unbalanced
Maximum Output Level Balanced: 0 dBV
Unbalanced: +6 dBV
Power Supply 100-240V AC (50/60 Hz) to 12V DC 0.5A, center positive, switched mode external power supply
Dimensions 4.72" (120.0 mm), headset, nominal at widest point 3.17" (80.5 mm), flexible boom 0.80" (20.4 mm), microphone diameter
Weight 2.1 oz (60 g)
RF Output Power 10 mW
Spurious Emission Following federal and national regulations
Input Connections 1x 4-pin locking connector
Wiring:
Pin 1: GND
Pin 2: INST INPUT
Pin 3: MIC INPUT
Pin 4: DC BIAS +9V
Batteries 2x 1.5V AA (not included)
Battery Life >7 hours (alkaline)
Element Dynamic
Polar Pattern Hypercardioid
Open Circuit Sensitivity -55 dB (1.7 mV) re 1V at 1 Pa
Impedance 600 ohms
Connector Locking 4-Pin HRS connector
Cable Length 55" (1.4 m)
