Audio-Technica ATW-1311L System 10 PRO Rack-Mount Digital Dual Lavalier Mic System (2.4 GHz)
  • Audio-Technica ATW-1311L System 10 PRO Rack-Mount Digital Dual Lavalier Mic System (2.4 GHz)

Special Order

Item Code: PAAUH00275 Part Number: ATW-1311/L

Audio-Technica ATW-1311L System 10 PRO Rack-Mount Digital Dual Lavalier Mic System (2.4 GHz)

Be the first to review this product

$1,299.00 Our Price

No Interest & No Payment for 6 months when you purchase this product in-store. [see financing options]

Bundled With

Original Price

Bundled Savings

Sale Price

Final Sale Item

Canada Computers Tech Protection

Order Online and Pick Up In-Store In-Store Special Order

The System 10 PRO ATW-1311L from Audio-Technica is a digital 24-bit/48 kHz wireless microphone system that operates on the 2.4 GHz ISM band and is used to capture audio for applications such as live stage, theater, DJ setups, and more.

The System 10 PRO features a half-rack chassis that allows you to mount one or two receiver units, however the receiver units can be released from the chassis and mounted remotely (up to 328' away) via Ethernet cable. Up to five chassis or 10 receiver units can be linked using a RJ12 cable, creating a multi-channel system with up to 10 channels.

In addition, other features include an easy-to-read display on each transmitter and receiver unit for quick setup, clear and natural-quality sound, and three levels of diversity, namely frequency, time, and space. Frequency Diversity sends the signal on two allocated frequencies, Time Diversity sends the signal in multiple time slots, and Space Diversity uses two antennas on each transmitter and receiver unit, thus to help maximize signal integrity.

The System 10 PRO Rack-Mount system includes one ATW-RC13 receiver chassis with rack-mount adapters, two ATW-RU13 receiver units with corresponding AT8690 receiver unit mounting brackets, one RJ12 cable, one AC adapter, two MT830cW lavalier microphones, and two ATW-T1001 bodypack transmitters.

Operating Frequencies 2.4 GHz ISM band
Dynamic Range > 109 dB (A-weighted), typical
Total Harmonic Distortion (THD) <0.05% typical
Operating Range 100' (30 m) typical
Operating Temperature Range 32 to 104°F (0 to 40°C)
Frequency Response 30 Hz to 20 kHz
Receiving System Diversity (frequency/time/space)
Output Connectors Locking 4-pin connector for use with Audio-Technica UniPak body-pack transmitters
Maximum Output Level v XLR Balanced: 0 dBV
1/4" (6.3 mm) Unbalanced: +6 dBV
Power Supply 100-240 VAC (50/60 Hz) to 12 VDC
0.5 A power supply switched mode external
Audio Sampling 24 bit / 48 kHz
Latency 3.8 ms
Remote Receiver Connector RJ45
Mounting Thread 1/4" x 20
Operating Frequency 2.4 GHz ISM band
Total Harmonic Distortion < 0.05% typical
RF Output Power 10 mW
Spurious Emission Following federal and national regulations
Input Connections Four-pin Locking Connector: Pin 1 - GND, Pin 2 - INST INPUT, Pin 3 - MIC INPUT, Pin 4 - DC BIAS 9 V
Battery Requirement Two 1.5 V AA (not included)
Battery Life > 7 hours (alkaline)
Element Fixed-charge back plate, permanently polarized condenser
Polar Pattern Omnidirectional
Low Frequency Roll-Off 80 Hz, 18 dB/octave - switchable
Open Circuit Sensitivity -37 dB (14.1 mV) re 1V @ 1 Pa
Output Impedance 200O
Maximum Input Sound Level 135 dB SPL, 1 kHz @ 1% THD
Dynamic Range (Typical) 108 dB, 1 kHz @ Max SPL
Signal-to-Noise Ratio 67 dB, 1 kHz @ 1 Pa
Phantom Power Requirements 11 to 52V DC, 2 mA typical
Cable 55" (1.4 m) permanently attached 2-conductor cable, shielded 0.10" (2.5 mm) diameter
