Audio |
Internal Speakers: 10W (x2) <br> Subwoofer: 15W (x1) |
|
Brand |
Viewsonic |
|
Connector |
HDMI 2.0 In(3), VGA(1), 3.5mm Audio In(1), 3.5mm Audio Out(1), SPDIF Audio Out(1), USB 3.0(4), USB 2.0(3), Slot-in PC Slot(1), USB B Touch Port(2), RS232(1), Ethernet LAN (RJ45)(1), WIFI Module Slot(1) |
|
Dimensions (imperial) (WxHxD) |
Packaging (in.): 76.0 x 44.9 x 11.0 <br> Physical (in.): 67.3 x 40.2 x 3.5 |
|
Dimensions (metric) (WxHxD) |
Packaging (mm): 1930.0 x 1140.0 x 280.0 <br> Physical (mm): 1710.0 x 1020.0 x 90.0 |
|
Display |
Display Type: LCD <br> Display Size (in.): 75 <br> Viewable Area (in.): 74.5 <br> Light Source: LED <br> Resolution: 3840 x 2160 <br> Refresh Rate (Hz): 60 <br> Aspect Ratio: 16:9 <br> Static Contrast Ratio: 1,200:1 <br> Dynamic Contrast Ratio: 5,000:1 <br> Backlight Life (Hours): 30,000 <br> Brightness: 350 cd/m2 <br> Response Time (Typical GTG): 8ms <br> Viewing Angles: 178º horizontal, 178º vertical <br> Panel Surface: 9H <br> Operation Rating: 16/7 |
|
Embedded Player |
OS: ViewBoard OS (embedded Android 8) <br> GPU: ARM Mali-G51 <br> CPU: ARM Quad Core A73 + A53 <br> CPU Processor Speed: A73: 1.1GHz; A53: 1.5GHz <br> Memory: 3GB <br> Storage: 32GB |
|
General |
Warranty: 3-year limited warranty on parts, labor and backlight, onsite warranty <br> Recycle/Disposal: Please dispose of in accordance with local, state or federal laws. <br> PACKAGE CONTENTS: IFP7550 display, stylus pen x 2, power cable, HDMI cable, USB cable, remote control with batteries, Camera plate, M8 screw x 8, Quick Start Guide <br> Regulations: cTUVus, FCC, ENERGY STAR, Mexico Energy, CE, CB, RoHS, ErP, WEEE |
|
Model |
766907901610 |
|
Mount |
VESA Compatible: 800 x 400 mm |
|
Networking |
Ethernet LAN: 10/100/1000 Mbps |
|
Operating Conditions |
Temperature: 32-104º F (0 - 40º C) <br> Humidity (non-condensing): 10-90% |
|
Power |
Voltage: 100-240 VAC <br> Consumption (max): 350W <br> Consumption (typical): 138W <br> Stand-by: <0.5W |
|
Touch |
Touch Technology: Infrared <br> Touch Points: 20-Point Touch <br> Tip Detection: Dual tips, 3mm and 8mm |
|
Weight (imperial) |
Net (lbs): 116.8 <br> Gross (lbs): 143.3 |
|
Weight (metric) |
Net (kg): 53.0 <br> Gross (kg): 65.0 |
