Part #: Z690 AORUS MASTER

Item Code: MBGIG00249OB

GIGABYTE Z690 AORUS MASTER LGA 1700 Intel Z690 ATX Motherboard with DDR5, Quad M.2, PCIe 5.0, USB 3.2 Gen2X2 Type-C, Intel WiFi 6E, AQUANTIA 10GbE LAN, Intel Thunderbolt 4(Open Box)

Name: GIGABYTE Z690 AORUS MASTER Intel LGA 1700 ATX Motherboard(Open Box)
Brand: GIGABYTE
SKU: MBGIG00249OB
Price: 354.24 CAD
Availability: SoldOut

GIGABYTE

Part #: Z690 AORUS MASTER

Item Code: MBGIG00249OB

GIGABYTE Z690 AORUS MASTER LGA 1700 Intel Z690 ATX Motherboard with DDR5, Quad M.2, PCIe 5.0, USB 3.2 Gen2X2 Type-C, Intel WiFi 6E, AQUANTIA 10GbE LAN, Intel Thunderbolt 4(Open Box)

15-day Low Price Guarantee

Limited . Time Offer! Sale Ends In

$354.24

SAVE $101.65

Get it NEW $372.88

Free Shipping

Qty:

Tech Care Replace Protection See Benefits

Tech Care Replace Protection

See Benefits

2 Year

$55.93
3 Year

$63.39

Availability

Delivery

Sold out online

Store Pickup

1 Available at London Masonville, ON

Check Other Stores >

Main Features

Support 12th Gen Intel® Series Processors
Dual Channel Non-ECC Unbuffered DDR5, 4 DIMMs
Direct 19+1+2 Phases VRM Design with 105A Power Stage* and Tantalum Polymer Capacitor
DDR5 XTREME MEMORY Design with SMD DIMM and Shielded Memory Routing
Advanced Thermal Solution with NanoCarbon Fins-Array III Heatsink, Direct-Touch Heatpipe II and NanoCarbon Baseplate
Intel® WIFI 6E 802.11ax 2T2R & BT5 with AORUS Antenna
Audio Solution with ESS Sabre ES9118 125dB on Rear Audio?
AQUANTIA® 10GbE BASE-T LAN
5 x Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2 with Thermal Guards
RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips

Marketing Information

Z690 AORUS MASTER | THE NEW KING OF GAMING

Rule supreme with the Z690 AORUS gaming motherboards. The new king of gaming platform continues the legendary AORUS bloodline with the most robust power delivery and dominant thermal design, glorified with the complete memory overclocking technology to crown your PC with the best Alder Lake's performance in all its gaming glory.

UNPARALLELED PERFORMANCE

With technology moving so fast, GIGABYTE still keep up with the latest trends and provide our customers with advanced features and latest technology. GIGABYTE Z690 Series motherboards come with upgraded power solution, latest storage standards and outstanding connectivity to enable optimize performance for gaming.

XTREME MEMORY

GIGABYTE Z690 Motherboards feature the latest DDR5 architecture and XMP 3.0 capability. The new DDR5 memory technology brings 50% more bandwidth to the platform and increases the system performance drastically by implementing Unlocked Native DDR5 Voltage, Xtreme Memory Routing and reliable SMD slot. In addition to the hardware upgrades, the user friendly UI provides full functionality to overclock higher with exclusive DDR5 tuning capability.

THERMAL REACTIVE ARMOR

GIGABYTE Z690 Series Motherboards' Un-throttled performance is guaranteed by innovative and optimized thermal design to ensure the best CPU, Chipset, SSD stability and low temperatures under full load application and gaming.

CONNECTIVITY

GIGABYTE Z690 Series Motherboards let you experience ultimate connection flexibility and blazing data-transfer speed with next generation network, storage, and WIFI connectivity.

PERSONALIZATION GIGABYTE

motherboards bundle several useful and intuitive software to help users to control every aspect of motherboard and provide customizable lighting effect with outstanding aesthetics to fit your unique personality.

ULTRA DURABLE GIGABYTE

Ultra Durable™ features its product durability and high-quality manufacturing process. GIGABYTE motherboards use the best components and reinforce every slots to make each of them solid and durable.

Return Period	15 Days
Defective Exchange Period	30 Days
Manufacturer Warranty	3 Years

Return Period	15 Days
Defective Exchange Period	30 Days
Manufacturer Warranty	3 Years

Model	Z690 AORUS MASTER
Memory Slots	4
Onboard LAN	Marvell® AQtion AQC113C 10GbE LAN chip
SATA 6Gb/s	6 x SATA 6Gb/s connectors
USB 2.0	4 x USB 2.0/1.1 ports available through the internal USB headers
USB 3.0	2 x USB Type-C ports, with USB 3.2 Gen 2x2 support <br> 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel <br> 1 x USB Type-C port on the back panel, with USB 3.2 Gen 2 support <br> 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel <br> 8 x USB 3.2 Gen 1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
Onboard Audio	Realtek® ALC1220-VB CODEC
DisplayPort	DisplayPort 1.2 version
Memory Channel Supported	Dual channel memory architecture
PCI Express 3.0 x16	2 x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2)
PCI Express 5.0 x16	1 x PCI Express x16 slot, running at x16 (PCIEX16)
Wireless	Intel® Wi-Fi 6E AX210
Brand	GIGABYTE
Chipset	Z690
Motherboard Form Factor	Extended ATX
Socket	LGA 1700
Platform	Intel
Memory Speed	DDR5 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MHz memory modulesDDR5 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MHz memory modules
Maximum Memory Supported	128GB
Bluetooth	BLUETOOTH 5.2
HDCP	HDCP 2.3
M.2	1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) <br> 2 x M.2 connectors (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_SB, M2Q_SB) <br> 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe 3.0 x4/x2 SSD support) (M2C_SB) <br> 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB)
Internal I/O Connectors	1 x 24-pin ATX main power connector <br> 2 x 8-pin ATX 12V power connectors <br> 1 x CPU fan header <br> 1 x water cooling CPU fan header <br> 4 x system fan headers <br> 4 x system fan/water cooling pump headers <br> 2 x addressable LED strip headers <br> 2 x RGB LED strip headers <br> 5 x M.2 Socket 3 connectors <br> 6 x SATA 6Gb/s connectors <br> 1 x front panel header <br> 1 x front panel audio header <br> 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support <br> 2 x USB 3.2 Gen 1 headers <br> 2 x USB 2.0/1.1 headers <br> 1 x noise detection header <br> 2 x Thunderbolt™ add-in card connectors <br> 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) <br> 1 x power button <br> 1 x reset button <br> 1 x reset jumper <br> 1 x Clear CMOS jumper <br> 2 x temperature sensor headers <br> Voltage Measurement Points
Back Panel Connectors	1 x Q-Flash Plus button <br> 1 x Clear CMOS button <br> 2 x SMA antenna connectors (2T2R) <br> 1 x DisplayPort <br> 1 x USB Type-C® port, with USB 3.2 Gen 2 support <br> 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support <br> 5 x USB 3.2 Gen 2 Type-A ports (red) <br> 4 x USB 3.2 Gen 1 ports <br> 1 x RJ-45 port <br> 1 x optical S/PDIF Out connector <br> 5 x audio jacks
I/O Controller	iTE® I/O Controller Chip

Model	Z690 AORUS MASTER
Memory Slots	4
Onboard LAN	Marvell® AQtion AQC113C 10GbE LAN chip
SATA 6Gb/s	6 x SATA 6Gb/s connectors
USB 2.0	4 x USB 2.0/1.1 ports available through the internal USB headers
USB 3.0	2 x USB Type-C ports, with USB 3.2 Gen 2x2 support <br> 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel <br> 1 x USB Type-C port on the back panel, with USB 3.2 Gen 2 support <br> 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel <br> 8 x USB 3.2 Gen 1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
Onboard Audio	Realtek® ALC1220-VB CODEC
DisplayPort	DisplayPort 1.2 version
Memory Channel Supported	Dual channel memory architecture
PCI Express 3.0 x16	2 x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2)
PCI Express 5.0 x16	1 x PCI Express x16 slot, running at x16 (PCIEX16)
Wireless	Intel® Wi-Fi 6E AX210
Brand	GIGABYTE
Chipset	Z690
Motherboard Form Factor	Extended ATX
Socket	LGA 1700
Platform	Intel
Memory Speed	DDR5 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MHz memory modulesDDR5 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MHz memory modules
Maximum Memory Supported	128GB
Bluetooth	BLUETOOTH 5.2
HDCP	HDCP 2.3
M.2	1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) <br> 2 x M.2 connectors (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_SB, M2Q_SB) <br> 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe 3.0 x4/x2 SSD support) (M2C_SB) <br> 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB)
Internal I/O Connectors	1 x 24-pin ATX main power connector <br> 2 x 8-pin ATX 12V power connectors <br> 1 x CPU fan header <br> 1 x water cooling CPU fan header <br> 4 x system fan headers <br> 4 x system fan/water cooling pump headers <br> 2 x addressable LED strip headers <br> 2 x RGB LED strip headers <br> 5 x M.2 Socket 3 connectors <br> 6 x SATA 6Gb/s connectors <br> 1 x front panel header <br> 1 x front panel audio header <br> 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support <br> 2 x USB 3.2 Gen 1 headers <br> 2 x USB 2.0/1.1 headers <br> 1 x noise detection header <br> 2 x Thunderbolt™ add-in card connectors <br> 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) <br> 1 x power button <br> 1 x reset button <br> 1 x reset jumper <br> 1 x Clear CMOS jumper <br> 2 x temperature sensor headers <br> Voltage Measurement Points
Back Panel Connectors	1 x Q-Flash Plus button <br> 1 x Clear CMOS button <br> 2 x SMA antenna connectors (2T2R) <br> 1 x DisplayPort <br> 1 x USB Type-C® port, with USB 3.2 Gen 2 support <br> 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support <br> 5 x USB 3.2 Gen 2 Type-A ports (red) <br> 4 x USB 3.2 Gen 1 ports <br> 1 x RJ-45 port <br> 1 x optical S/PDIF Out connector <br> 5 x audio jacks
I/O Controller	iTE® I/O Controller Chip
