ASUS

Part #: ROG MAXIMUS Z690 APEX

Item Code: MBASU00400OB

ASUS ROG Maximus Z690 Apex (WiFi 6E) LGA 1700(Intel12th Gen) ATX gaming motherboard (PCIe 5.0, DDR5,24+0 power stages,5x M.2,1xPCIe 5.0 M.2,USB 3.2 Gen 2x2 front-panel connector with Quick Charge 4+ Support,PCIe 5.0 Hyper M.2 Card bundled) ROG MAXIMUS Z690 APEX(Open Box)

Name: ASUS ROG Maximus Z690 Apex (WiFi 6E) LGA 1700(Intel12th Gen) ATX gaming motherboard (PCIe 5.0, DDR5,24+0 power stages,5x M.2...
Brand: ASUS
SKU: MBASU00400OB
Price: 374.19 CAD
Availability: SoldOut

ASUS

Part #: ROG MAXIMUS Z690 APEX

Item Code: MBASU00400OB

ASUS ROG Maximus Z690 Apex (WiFi 6E) LGA 1700(Intel12th Gen) ATX gaming motherboard (PCIe 5.0, DDR5,24+0 power stages,5x M.2,1xPCIe 5.0 M.2,USB 3.2 Gen 2x2 front-panel connector with Quick Charge 4+ Support,PCIe 5.0 Hyper M.2 Card bundled) ROG MAXIMUS Z690 APEX(Open Box)

15-day Low Price Guarantee

Limited . Time Offer! Sale Ends In

$374.19

SAVE $81.70

Get it NEW $393.88

Qty:

Tech Care Replace Protection See Benefits

Tech Care Replace Protection

See Benefits

2 Year

$59.08
3 Year

$66.96

Availability

Delivery

Sold out online

Store Pickup

1 Available at Cambridge, ON

Check Other Stores >

Main Features

Experience responsive performance, power and adaptability with the compatible Intel Celeron processor
DDR5 SDRAM slot for convenient installation of memory
Supported 0 RAID levels provide data reliability and fault tolerance
IEEE 802.11 a/b/g/n/ac/ax wireless standard support enables a hassle-free peripheral connection
ATX form factor brings a significant number of PCI slots, expansion slots, and peripheral ports with an enhanced heat dissipation capability

Marketing Information

Intel^® Z690 ATX motherboard with 24+0 power stages, DDR5, Five M.2, USB 3.2 Gen 2x2 front-panel connector with Quick Charge 4+ Support, PCIe^® 5.0, Onboard Wi-Fi 6E and Aura Sync RGB lighting

Socket LGA1700 for 12th Gen Intel^® Core™, Pentium^® Gold and Celeron^® Processors
Intelligent Control: ASUS-exclusive tools including AI Overclocking, AI Cooling, AI Networking and Two-Way AI Noise-Cancelation for easy configuration
Robust Power Solution: 24+0 teamed power stages rated for 105 A, ProCool II power connectors, MicroFine alloy chokes and premium metallic capacitors
Optimized Thermal Design: Enlarged VRM heatsinks plus integrated aluminum I/O cover, high-conductivity thermal pad, dual M.2 heatsinks with embedded backplates and ROG Water-Cooling Zone
High Performance Networking: Onboard Wi-Fi 6E, Intel^® 2.5Gb Ethernet, and ASUS LANGuard.
Fastest Gaming Connectivity: PCIe^® 5.0, PCIE 5.0 M.2 card with Gen 5 M.2, USB 3.2 Gen 2x2 front-panel connector
Industry Leading Audio: ROG SupremeFX ALC4080 codec with Savitech SV3H712 amplifier for high-fidelity audio
Unmatched Personalization: ASUS-exclusive Aura Sync RGB lighting, including one RGB header and three addressable Gen 2 RGB headers
DIY Friendly Design: Pre-mounted I/O shield, PCIe Slot Q-Release, V-Latch switch, BIOS FlashBack™, Q-Code, FlexKey, Q-Connector, SafeSlot and ROG graphics card holder
Renowned Software: Bundled 1-year AIDA64 Extreme subscription and intuitive UEFI BIOS dashboard with integrated MemTest86

ROG Maximus Z690 Apex

ROG Maximus Z690 Apex is the premiere choice for those who seek a combination of raw speed and cutting-edge tech like DDR5 memory, PCIe 5.0, and truckloads of power delivery for the most performant 12th Gen Intel Core processors available. Its streamlined layout is engineered for ultra-low latency and maximal bandwidth, to empower users to discover the limits of performance and define new world records.

AUTO-EXTREME TECHNOLOGY

Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.

OVERCLOCKING

ROG Maximus Z690 Apex makes overclocking accessible to both beginners and seasoned enthusiasts alike. Its beef-up power solution caters to the demands of 12^th Gen Intel processors, while ASUS Enhanced Memory Profile technology makes it easy to ramp up DDR5 performance.

COOLING

A comprehensive cooling solution is vital to a pursuit of performance. ROG Maximus Z690 Apex includes robust heatsinks and the ROG Water-Cooling Zone, a set of fan and sensor headers that help keep temperatures in check.

CONNECTIVITY

Maximus Z690 Apex delivers supersmooth WiFi 6E connectivity, extensive M.2 slots, and high-end audio - the essentials for any setup.

OPTIMIZATION

ROG Maximus Z690 Apex is packed with intuitive and flexible tools like 5-Way Optimization and a UEFI BIOS interface, giving users next-level control of system performance.

Return Period	15 Days
Defective Exchange Period	30 Days
Manufacturer Warranty	3 Years

Return Period	15 Days
Defective Exchange Period	30 Days
Manufacturer Warranty	3 Years

Model	ROG MAXIMUS Z690 APEX
Memory Slots	2
Onboard LAN	1 x Intel® 2.5Gb <br> Ethernet ASUS LANGuard
SATA 6Gb/s	6 x SATA 6Gb/s ports
Onboard Audio	ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
Memory Channel Supported	Dual Channel Memory Architecture
PCI Express 5.0 x16	2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 modes)
USB	Rear USB (Total 10 ports) <br> 1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C) <br> 5 x USB 3.2 Gen 2 port(s) (5 x Type-A) <br> 4 x USB 3.2 Gen 1 port(s) (4 x Type-A) <br> <br> Front USB (Total 9 ports) 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C) <br> 2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports <br> 2 x USB 2.0 headers support additional 4 USB 2.0 ports <br> Front USB (Total 9 ports) <br> 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C) <br> 2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports <br> 2 x USB 2.0 headers support additional 4 USB 2.0 ports
Wireless	Wi-Fi 6E <br> 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
Brand	ASUS
Chipset	Z690
Motherboard Form Factor	ATX
Socket	LGA 1700
Platform	Intel
Memory Speed	64GB
Maximum Memory Supported	6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC) / 4800 Non-ECC, Un-buffered Memory
Bluetooth	Bluetooth v5.2
PCI Express 5.0 x4	1 x PCIe 3.0 x4 slot
PCI Express 3.0 x1	1 x PCIe 3.0 x1 slot
Back Panel I/O Ports	1 x Thunderbolt 4 USB Type-C port <br> 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) <br> 8 x USB 3.2 Gen 2 ports (7 x Type-A + 1 x USB Type-C) <br> 1 x HDMI port <br> 1 x ASUS Wi-Fi Module <br> 1 x Intel 2.5Gb Ethernet port <br> 1 x Marvell AQtion 10Gb Ethernet port <br> 5 x LED-illuminated audio jacks <br> 1 x Optical S/PDIF out port <br> 1 x BIOS FlashBack button <br> 1 x Clear CMOS button 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) <br> 5 x USB 3.2 Gen 2 ports (5 x Type-A) <br> 4 x USB 3.2 Gen 1 ports (4 x Type-A) <br> 1 x Wi-Fi Module <br> 1 x Intel 2.5Gb Ethernet port <br> 5 x Gold-plated audio jacks <br> 1 x Optical S/PDIF out port <br> 1 x BIOS FlashBack button <br> 1 x Clear CMOS button <br> 1 x PS/2 Keyboard (purple) port <br> 1 x PS/2 Mouse (green) port
Internal I/O Connectors	Fan and Cooling related <br> 1 x 4-pin CPU Fan header(s) <br> 1 x 4-pin CPU OPT Fan header(s) <br> 1 x 4-pin AIO Pump header(s) <br> 3 x 4-pin Chassis Fan header(s) <br> 2 x 4-pin Full Speed Fan header(s) <br> 1 x W_PUMP+ header(s) <br> 1 x 2-pin Water In header <br> 1 x 2-pin Water Out header <br> 1 x 3-pin Water Flow header <br> Power related <br> 1 x 24-pin Main Power connector <br> 2 x 8-pin +12V Power connector <br> 1 x 6-pin PCIe Graphics Card connector <br> Storage related <br> 2 x M.2 slots (Key M) <br> 1 x DIMM.2 slot supports <br> 2 x M.2 slots (Key M) <br> 6 x SATA 6Gb/s ports <br> USB <br> 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C) <br> 2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports <br> 2 x USB 2.0 headers support additional 4 USB 2.0 ports <br> Miscellaneous <br> 1 x 80 Light Bar jumper <br> 3 x Addressable Gen 2 header(s) <br> 1 x AURA RGB header(s) <br> 2 x BCLK button <br> 1 x BIOS Switch button <b
M.2	5 x M.2 slots

Model	ROG MAXIMUS Z690 APEX
Memory Slots	2
Onboard LAN	1 x Intel® 2.5Gb <br> Ethernet ASUS LANGuard
SATA 6Gb/s	6 x SATA 6Gb/s ports
Onboard Audio	ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
Memory Channel Supported	Dual Channel Memory Architecture
PCI Express 5.0 x16	2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 modes)
USB	Rear USB (Total 10 ports) <br> 1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C) <br> 5 x USB 3.2 Gen 2 port(s) (5 x Type-A) <br> 4 x USB 3.2 Gen 1 port(s) (4 x Type-A) <br> <br> Front USB (Total 9 ports) 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C) <br> 2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports <br> 2 x USB 2.0 headers support additional 4 USB 2.0 ports <br> Front USB (Total 9 ports) <br> 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C) <br> 2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports <br> 2 x USB 2.0 headers support additional 4 USB 2.0 ports
Wireless	Wi-Fi 6E <br> 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
Brand	ASUS
Chipset	Z690
Motherboard Form Factor	ATX
Socket	LGA 1700
Platform	Intel
Memory Speed	64GB
Maximum Memory Supported	6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC) / 4800 Non-ECC, Un-buffered Memory
Bluetooth	Bluetooth v5.2
PCI Express 5.0 x4	1 x PCIe 3.0 x4 slot
PCI Express 3.0 x1	1 x PCIe 3.0 x1 slot
Back Panel I/O Ports	1 x Thunderbolt 4 USB Type-C port <br> 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) <br> 8 x USB 3.2 Gen 2 ports (7 x Type-A + 1 x USB Type-C) <br> 1 x HDMI port <br> 1 x ASUS Wi-Fi Module <br> 1 x Intel 2.5Gb Ethernet port <br> 1 x Marvell AQtion 10Gb Ethernet port <br> 5 x LED-illuminated audio jacks <br> 1 x Optical S/PDIF out port <br> 1 x BIOS FlashBack button <br> 1 x Clear CMOS button 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) <br> 5 x USB 3.2 Gen 2 ports (5 x Type-A) <br> 4 x USB 3.2 Gen 1 ports (4 x Type-A) <br> 1 x Wi-Fi Module <br> 1 x Intel 2.5Gb Ethernet port <br> 5 x Gold-plated audio jacks <br> 1 x Optical S/PDIF out port <br> 1 x BIOS FlashBack button <br> 1 x Clear CMOS button <br> 1 x PS/2 Keyboard (purple) port <br> 1 x PS/2 Mouse (green) port
Internal I/O Connectors	Fan and Cooling related <br> 1 x 4-pin CPU Fan header(s) <br> 1 x 4-pin CPU OPT Fan header(s) <br> 1 x 4-pin AIO Pump header(s) <br> 3 x 4-pin Chassis Fan header(s) <br> 2 x 4-pin Full Speed Fan header(s) <br> 1 x W_PUMP+ header(s) <br> 1 x 2-pin Water In header <br> 1 x 2-pin Water Out header <br> 1 x 3-pin Water Flow header <br> Power related <br> 1 x 24-pin Main Power connector <br> 2 x 8-pin +12V Power connector <br> 1 x 6-pin PCIe Graphics Card connector <br> Storage related <br> 2 x M.2 slots (Key M) <br> 1 x DIMM.2 slot supports <br> 2 x M.2 slots (Key M) <br> 6 x SATA 6Gb/s ports <br> USB <br> 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C) <br> 2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports <br> 2 x USB 2.0 headers support additional 4 USB 2.0 ports <br> Miscellaneous <br> 1 x 80 Light Bar jumper <br> 3 x Addressable Gen 2 header(s) <br> 1 x AURA RGB header(s) <br> 2 x BCLK button <br> 1 x BIOS Switch button <b
M.2	5 x M.2 slots
