Supermicro SuperServer SYS-6016T-NTRF Intel® Xeon® processor 5600/5500, DDR3 1333MHz; 12x DIMM slots (SYS-6016T-NTRF)

Name: Supermicro SuperServer SYS-6016T-NTRF Intel® Xeon® processor 5600/5500, DDR3 1333MHz; 12x DIMM slots (SYS-6016T-NTRF)
Brand: SUPERMICRO
SKU: SRSUM00107
Price: 1725 CAD
Availability: SoldOut

SUPERMICRO

Part #: SYS-6016T-NTRF

Item Code: SRSUM00107

Supermicro SuperServer SYS-6016T-NTRF Intel® Xeon® processor 5600/5500, DDR3 1333MHz; 12x DIMM slots (SYS-6016T-NTRF)

15-day Low Price Guarantee

$1,725.00

Qty:

Tech Care Repair Protection See Benefits

Tech Care Repair Protection

See Benefits

2 Year

$310.50
3 Year

$345.00
4 Year

$414.00

Availability

CUSTOM ORDER

AVAILABLE TO ORDER

Returns are only accepted for defective items; all other sales are final.
Delivery times may vary. You will be notified once your order is ready to ship.
Custom order products cannot be canceled once the order is placed.

Main Features

Experience high performance, built-in security and remote management capabilities with Intel Xeon processor
DDR3 SDRAM compatible slot - Install memory that synchronizes electrical and clock signals for an efficient data throughput
Featuring Gigabit Ethernet port for ultra-fast network speeds
Connect USB-enabled devices via 4 USB ports
Have greater throughput and superb reliability with Serial ATA/300 interface

Marketing Information

Designed for optimal performance, the dual-processor SuperServer 6016T-NTRF Barebone System support the QPI format quad-core/dual-core Xeon processors in a high-density 2U form-factor. This SuperServer is ideal for network infrastructure, front-end enterprise, and minimal-downtime cluster server systems.

Defective Exchange Period

30 Days

Defective Exchange Period

30 Days

Buttons	Power On/Off button <br/>UID button
Certification	Gold Certified
CPU	Monitors for CPU Cores,+1.5V, +3.3V, +5V, +12V, +5 Stdby, +3.3 Stdby, VBAT, Memory Voltages. <br/>CPU Core 6-Phase-switching voltage regulator
Fan	Total of four 4-pin PWM fans <br/>4x fans with tachometer monitoring <br/>Status monitor for speed control <br/>Status monitor for on/off control <br/>Low noise fan speed control
Graphics	Matrox G200eW
LAN	2x RJ45 LAN ports <br/>1x RJ45 Dedicated IPMI LAN port
Memory Capacity	12x 240-pin DIMM slots <br/>Supports up to 192 GB 1333 / 1066 / 800MHz DDR3 ECC Registered memory <br/>Supports up to 48 GB 1333 / 1066 / 800MHz DDR3 ECC / Non ECC Unbuffered memory <br/>Memory Mirroring supported
Memory Type	1333 / 1066 / 800MHz ECC Registered / ECC or Non ECC Unbuffered DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs
Model	CSE-827H-R1400B
Motherboard	4x Super X8DTT-HF+
Other Features	SDDC Support
USB	2 rear + 1 header (2 Ports) <br/>4 total USB ports, 2.0 Compliant / 1.1 Compliant
VGA	1 x VGA Port
Weight	85 lbs (38.6kg)
With Power Distributor	+5V: 30 Amp <br/>+3.3V: 24 Amp <br/>-12V: 0.6 Amp
PCI-Express	1 (x16) PCI-E ( Low Profile)
Super I/O	Winbond W83527HG chip
System Bus	up to 6.4 GT/s
Temperature	Monitoring for CPU and chassis environment <br/>CPU thermal trip support <br/>Thermal Control for 4x Fan Connectors <br/>PSU I2C temperature sensing logic <br/>Thermal Monitor 2 (TM2) support <br/>PECI
RoHS	RoHS Compliant
SATA	Intel ICH10R SATA 3.0Gbps Controller <br/>RAID 0, 1, 5, 10 support (Windows) <br/>RAID 0, 1, 10 support (Linux)
Serial ATA	Six Serial ATA ports <br/>3 SATA hard drives supported
Serial Port	1 Fast UART 16550 serial port
Network Controllers	Dual Intel® 82574L Gigabit Ethernet Controller <br/>Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output <br/>1x Realtek RTL8201N PHY (dedicated IPMI)
Memory Voltage	1.5 V, 1.35 V
LED	Power Fail / Overheat LED <br/>Suspend-state Indicator LED <br/>UID LED
LEDs	Power LED (on power button) <br/>Network activity LED <br/>System Overheat/fan fail/power fail/ LED <br/>UID LED (on UID button)
Hot-swap	3x 3.5" SATA Hot-swap drive bays
IPMI	Support for Intelligent Platform Management Interface v.2.0 <br/>IPMI 2.0 with virtual media over LAN and KVM-over-LAN support <br/>Nuvoton WPCM450 BMC
Fans	4x Cooling Fans
Form Factor	2U Rackmount
Chipset	Intel® 5500 (Tylersburg) chipset ICH10R + IOH-36D
Clock Generator	932S421 chip
DC Output	1100W: +12V/92A; +5Vsb/4A <br/>1400W: +12V/116A; +5Vsb/4A
Dimensions (D x W x H)	28.5 x 17.2 x 3.5" (72.4 x 43.7 x 8.9 cm)
DIMM Sizes	1GB, 2GB, 4GB , 8GB , 16GB
Environmental Spec.	Operating Temperature: <br/>10°C to 35°C (50°F to 95°F) <br/>Non-operating Temperature: <br/>-40°C to 70°C (-40°F to 158°F) <br/>Operating Relative Humidity: <br/>8% to 90% (non-condensing) <br/>Non-operating Relative Humidity: <br/>5% to 95% (non-condensing)
Error Detection	Corrects single-bit errors <br/>Detects double-bit errors (using ECC memory) <br/>Supports Intel® x4 and x8 Single Device Data Correction (SDDC)
Backplane	2U Hard drive Backplane
Power Supply	1400W high-efficiency (1+1) redundant power supply with PMBus
AC Input	1100W Output @ 100-140V, 13.5-9.5A, 50-60Hz <br/>1400W Output @ 180-240V, 9.5-7.0A, 50-60Hz
Available Colours	Black
BIOS Features	Plug and Play (PnP) <br/>PCI 2.2 <br/>ACPI up to 3.0 <br/>USB Keyboard support
BIOS Type	32Mb SPI Flash EEPROM with AMI® BIOS

Buttons	Power On/Off button <br/>UID button
Certification	Gold Certified
CPU	Monitors for CPU Cores,+1.5V, +3.3V, +5V, +12V, +5 Stdby, +3.3 Stdby, VBAT, Memory Voltages. <br/>CPU Core 6-Phase-switching voltage regulator
Fan	Total of four 4-pin PWM fans <br/>4x fans with tachometer monitoring <br/>Status monitor for speed control <br/>Status monitor for on/off control <br/>Low noise fan speed control
Graphics	Matrox G200eW
LAN	2x RJ45 LAN ports <br/>1x RJ45 Dedicated IPMI LAN port
Memory Capacity	12x 240-pin DIMM slots <br/>Supports up to 192 GB 1333 / 1066 / 800MHz DDR3 ECC Registered memory <br/>Supports up to 48 GB 1333 / 1066 / 800MHz DDR3 ECC / Non ECC Unbuffered memory <br/>Memory Mirroring supported
Memory Type	1333 / 1066 / 800MHz ECC Registered / ECC or Non ECC Unbuffered DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs
Model	CSE-827H-R1400B
Motherboard	4x Super X8DTT-HF+
Other Features	SDDC Support
USB	2 rear + 1 header (2 Ports) <br/>4 total USB ports, 2.0 Compliant / 1.1 Compliant
VGA	1 x VGA Port
Weight	85 lbs (38.6kg)
With Power Distributor	+5V: 30 Amp <br/>+3.3V: 24 Amp <br/>-12V: 0.6 Amp
PCI-Express	1 (x16) PCI-E ( Low Profile)
Super I/O	Winbond W83527HG chip
System Bus	up to 6.4 GT/s
Temperature	Monitoring for CPU and chassis environment <br/>CPU thermal trip support <br/>Thermal Control for 4x Fan Connectors <br/>PSU I2C temperature sensing logic <br/>Thermal Monitor 2 (TM2) support <br/>PECI
RoHS	RoHS Compliant
SATA	Intel ICH10R SATA 3.0Gbps Controller <br/>RAID 0, 1, 5, 10 support (Windows) <br/>RAID 0, 1, 10 support (Linux)
Serial ATA	Six Serial ATA ports <br/>3 SATA hard drives supported
Serial Port	1 Fast UART 16550 serial port
Network Controllers	Dual Intel® 82574L Gigabit Ethernet Controller <br/>Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output <br/>1x Realtek RTL8201N PHY (dedicated IPMI)
Memory Voltage	1.5 V, 1.35 V
LED	Power Fail / Overheat LED <br/>Suspend-state Indicator LED <br/>UID LED
LEDs	Power LED (on power button) <br/>Network activity LED <br/>System Overheat/fan fail/power fail/ LED <br/>UID LED (on UID button)
Hot-swap	3x 3.5" SATA Hot-swap drive bays
IPMI	Support for Intelligent Platform Management Interface v.2.0 <br/>IPMI 2.0 with virtual media over LAN and KVM-over-LAN support <br/>Nuvoton WPCM450 BMC
Fans	4x Cooling Fans
Form Factor	2U Rackmount
Chipset	Intel® 5500 (Tylersburg) chipset ICH10R + IOH-36D
Clock Generator	932S421 chip
DC Output	1100W: +12V/92A; +5Vsb/4A <br/>1400W: +12V/116A; +5Vsb/4A
Dimensions (D x W x H)	28.5 x 17.2 x 3.5" (72.4 x 43.7 x 8.9 cm)
DIMM Sizes	1GB, 2GB, 4GB , 8GB , 16GB
Environmental Spec.	Operating Temperature: <br/>10°C to 35°C (50°F to 95°F) <br/>Non-operating Temperature: <br/>-40°C to 70°C (-40°F to 158°F) <br/>Operating Relative Humidity: <br/>8% to 90% (non-condensing) <br/>Non-operating Relative Humidity: <br/>5% to 95% (non-condensing)
Error Detection	Corrects single-bit errors <br/>Detects double-bit errors (using ECC memory) <br/>Supports Intel® x4 and x8 Single Device Data Correction (SDDC)
Backplane	2U Hard drive Backplane
Power Supply	1400W high-efficiency (1+1) redundant power supply with PMBus
AC Input	1100W Output @ 100-140V, 13.5-9.5A, 50-60Hz <br/>1400W Output @ 180-240V, 9.5-7.0A, 50-60Hz
Available Colours	Black
BIOS Features	Plug and Play (PnP) <br/>PCI 2.2 <br/>ACPI up to 3.0 <br/>USB Keyboard support
BIOS Type	32Mb SPI Flash EEPROM with AMI® BIOS
