With 20 Hz - 20 kHz frequency range, listen to deep lows and euphoric highs
Fits into the stand. You can mount, unmount or remount it according to what situation demands.
Marketing Information
The AT2022 is a condenser microphone designed for stereo recording. Two unidirectional condenser capsules in an X/Y configuration pivot to allow for narrow (90°) or wide (120°) stereo operation. The capsules also fold flat for storage and transportation. Designed for general stereo recording and field sound capture, the AT2022 provides the spatial impact and realism of a live sound field. The microphone comes equipped with a stand clamp, AA battery, fuzzy windscreen and .5 m cable that terminates in a 3.5 mm stereo plug.
Dimensions
7.56" (192.0mm) Length <br/>2.56" (65.0mm) Head Diameter <br/>0.83" (21.0mm) Body Diameter
Dynamic Range (Typical)
103dB, 1 kHz at Max SPL
Frequency Response
20Hz - 20kHz
Low Frequency Roll-Off
150Hz, 6 dB/octave
Maximum Input Sound Level
122 dB SPL, 1 kHz at 1% T.H.D.
Output Connectors
Integral 3-pin XLRM-type
Output Impedance
200 ohms
Pad
None
Polar Pattern
X/Y Stereo
Power Requirements
1.5V AA/UM3 <br/>WARNING: The AT2022 is designed for battery operation only. Do not attempt to use when phantom power is present. Possible damage to the microphone may result. BATTERY CURRENT / LIFE 1.2 mA / 500 hours typical (alkaline)
Signal-to-Noise Ratio
75dB, 1kHz at 1 Pa
Transducer
Fixed-charge back plate, permanently polarized condenser
Weight
9.5 oz (270g)
Dimensions
7.56" (192.0mm) Length <br/>2.56" (65.0mm) Head Diameter <br/>0.83" (21.0mm) Body Diameter
Dynamic Range (Typical)
103dB, 1 kHz at Max SPL
Frequency Response
20Hz - 20kHz
Low Frequency Roll-Off
150Hz, 6 dB/octave
Maximum Input Sound Level
122 dB SPL, 1 kHz at 1% T.H.D.
Output Connectors
Integral 3-pin XLRM-type
Output Impedance
200 ohms
Pad
None
Polar Pattern
X/Y Stereo
Power Requirements
1.5V AA/UM3 <br/>WARNING: The AT2022 is designed for battery operation only. Do not attempt to use when phantom power is present. Possible damage to the microphone may result. BATTERY CURRENT / LIFE 1.2 mA / 500 hours typical (alkaline)
Signal-to-Noise Ratio
75dB, 1kHz at 1 Pa
Transducer
Fixed-charge back plate, permanently polarized condenser
Weight
9.5 oz (270g)
